Cyclops
Passive slimline subwoofer
The Cyclops subwoofer is a discreet and weatherproof audio solution designed to deliver rich and impactful bass in small spaces. Ideal for those who want high-quality sound without sacrificing space or design aesthetics, the Cyclops is perfect for both indoor and outdoor use.
Pictured: Alderwood installation featuring the Cyclops subwoofer at Cobar Miners Memorial, NSW
Big bass
With advanced technology and high-quality materials, the big bass of the Cyclops is made possible. It features a 10-inch bass driver with butyl rubber suspension, high-strength neodymium magnet assembly, and premium birch ply cabinet with a hexagram pattern.
10 inch 24mm excursion driver
Butyl rubber suspension
Neodymium magnet assembly
76mm voice coil
Reinforced birch cabinet
Pictured: Alderwood marine installation by The Wooden Boat Shop featuring the Cyclops.
Made for marine
The Cyclops is perfect for marine installations due to its corrosion-resistant properties, IP66 rating, and slim, concealable design. It is resistant to rust and other forms of corrosion thanks to its marine-rated alloy grille and stainless steel fasteners, and its IP66 rating safeguards against harsh marine environments.
Corrosion-resistant
IP66 rated
Slim concealable design
Discreet sound
With its small size, lightweight, and multiple mounting points, the Cyclops is an ideal choice for discreet installations. Even in cramped spaces, its compact design can be easily accommodated while delivering excellent sound quality.
Small and compact
34x34x12.5cm
Mounting socket threads
4x M5 front,4x M5 back, 8x M8 sides
Made thoughtfully
The Cyclops is sustainably made with responsibly sourced premium birch timber, precise CNC manufacturing for reduced wastage, and durable high-quality components and construction for a longer product lifespan.
Responsibly sourced timber
Precision machined
Premium components
Longer lifespan
The finer details
CYCLOPS
Nominal Impedance
8 Ohms
6.5 Ohms
A/C impedance
350 watts RMS
Power Handling
85 dB
Sensitivity @ 1Mtr
35 - 250 Hz
Frequency Range
Omni
Beamwidth
Input Connector
1 meter sealed cable
34 x 34 x 12.5cm
Dimensions
7.2 kg
Weight
Colours
Black / White
F17 rated birch ply
Cabinet material
M5x8 Front/Back, M8x8 sides
Mounting socket thread
IP66
Environmental rating
10 inch long throw
Driver size
Driver suspension surround
Butyl rubber
Diaphragm maintenance
None
High Temp Neodymium - copper shorting ring
Magnet assembly
Moving mass
170 gram
Maximum cone excursion
24mm
Magnetic circuit weight
2.6 kg
Guass
1 Tesla
In the box
Cyclops
Manual
